DC Power Supply SIGLENT SPD3303X-E

id: 862795
DC Power Supply SIGLENT SPD3303X-E
Overview
Description
Specifications
Delivery
Payment
Warranty
USD 342.32

Overview

DC Power Supply SIGLENT SPD3303X E
5 (1)
9.5 kg 110, 220 V Warranty: 36 months
Programmable high-precision linear DC power supply with 3 output channels and a 220 W max. output power. 4.3-inch TFT LCD (4 digits voltage / 3 digits current). Read more
USD 342.32
USD 342.32
Impossible to estimate the shipping cost

You may also like

Description

Siglent SPD3303X-E is a programmable high-precision linear DC power supply with 3 output channels and a 220 W max. output power.

Features

  • 3 independent controlled and isolated outputs
    • 32 V / 3.2 A × 2
    • 2.5 V / 3.3 V / 5 V / 3.2 A × 1
  • 4 digits voltage, 3 digits current display, minimum resolution: 10 mV / 10 mA
  • 3 output modes: independent, series and parallel connect
  • 4.3-inch TFT-LCD display with 480×272 resolution
  • 100 V / 120 V / 220 V / 230 V compatible design
  • Intelligent temperature-controlled fan
  • Clear graphical interface, with the waveform display function
  • Save/recall 5 group system specifications, supports data storage expansion

Technical Specifications

Channels CH1： 0 ～ 32 V， 0 ～ 3.2 A
CH2： 0 ～ 32 V， 0 ～ 3.2 A
CH3： 2.5/3.3/5.0 V， 3.2 A
Max output power 220 W
Resolution 10 mV / 10 mA
Voltage/Current display digits 4.3-inch TFT-LCD 480×272
4 digits voltage and 3 digits current display
Ripple noise ≤1 mVrms (5 Hz - 1 MHz)
Standard interfaces LAN, USB
Dimensions 225 × 143 × 278 mm
Weight 8 kg

Package Contents

  • Siglent SPD3303X-E power supply – 1 pc.
  • Power cable – 1 pc.
  • USB cable – 1 pc.
  • Crocodile clips – 1 set
  • Software CD and user manual – 1 set
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
All rights reserved. This material from gsmserver.com web site may not be published, rewritten or redistributed in whole or part without authorship indicated and backlinks provided.

Specifications

Type
  • transformer
  • programmable
Number of channels
  • three-channel
Max. Current
  • up to 3 A
Max. Voltage
  • up to 32 V
Indicator type
  • 4.3" color LCD display
Maximum power
  • 220 W
