Digital Clamp Meter UNI-T UT221
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
USD 149.62
Overview
Video
Video
Video
1 kg Warranty: 24 months
The reliable True RMS digital clamp meter for measuring AC/DC current, AC/DC voltage, resistance, frequency and performing diode check and continuity test. Read more
USD 149.62
Buy wholesale and save
Description
UNI-T UT221 is reliable digital clamp meter that is designed for measuring AC/DC current, AC/DC voltage, resistance, frequency and performing diode check and continuity test.
Features
- Functions:
- AC/DC voltage
- AC/DC current
- resistance
- frequency
- continuity test
- diode test
- True RMS device
- Data hold
- Auto ranging.
- Auto power-off function.
- Low battery display.
Video
You'll find even more video reviews in the Video tab. Go and check it out!
Technical Specifications
| AC current | Range | 660 A / 2000 A |
| Accuracy | ±(2.5%+5) | |
| DC current | Range | 660 A / 2000 A |
| Accuracy | ±(2.5%+5) | |
| AC voltage | Range | 6.6 V / 66 V / 660 V / 750 V |
| Accuracy | ±(1.2%+5) | |
| DC voltage | Range | 6.6 V / 66 V / 660 V / 750 V |
| Accuracy | ±(0.8%+5) | |
| Resistance | Range | 660 Ω / 6.6 kΩ / 66 kΩ / 660 kΩ / 6.6 MΩ / 66 MΩ |
| Frequency | Range | 66 Hz / 660 Hz / 6.6 kHz / 66 kHz / 660 kHz / 6.6 MHz / 20 MHz |
| Power | 9 V battery (6LF22) | |
| Dimensions (H × W × D) | 298 × 100 × 48 mm | |
| Weight | 725 g | |
Package Contents
- UNI-T UT221 clamp meter (1 pc.)
- Test leads (1 pair)
- User manual (1 pc.)
- Analog output connection cable (1 pc.)
- Strap (1 pc.)
- Case (1 pc.)
Note! Batteries are not included in the package.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
