Arbitrary Waveform / Function Generator SIGLENT SSG3021X
id: 893847
10.37 kg Warranty: 36 months
Single-channel function/arbitary waveform generator with a frequency range of 9 kHz to 2.1 GHz and output levels from -110 dBm to +13 dBm. Functions: AM, FM, and PM. Read more
Buy wholesale and save
Inform of price reduction
SIGLENT SSG3021X is a single-channel signal generator with a frequency range from 9 kHz to 2.1 GHz. The device is capable of generating multiple waveform types, including sine wave, square wave, saw-tooth, triangle, DC.
The generator is equipped with a large color screen and the remote control function. The built-in USB interface allows the device to be connected up to a PC or other similar device via the included USB cable.
Features
- Includes built-in high precision, 200 MHz frequency counter.
- Multiple modulation functions, sweep-frequency function, pulse train function.
- Standard PC connections: USB Device, USB Host, U-Disk storage and software.
- Seamlessly connects to the SDS series digital oscilloscopes.
- Remote computer control.
Technical Specifications
Model | SSG3021X | SSG3032X | SSG3021X-IQE | SSG3032X-IQE |
Frequency Range | 9 kHz~2.1 GHz (CW mode) | 9 kHz~3.2 GHz (CW mode) | 9 kHz~2.1 GHz (CW mode) 10 MHz~2.1 GHz (IQ mode) |
9 kHz~3.2 GHz (CW mode) 10 MHz~3.2 GHz (IQ mode) |
Frequency Resolution | 0.01 Hz | |||
Amplitude Resolution | 0.01 dB | |||
Level accuracy | 0.7 dB (typ.) | |||
Phase noise | -110 dBc/Hz at 1 GHz | |||
Display | 5 inch capacitance touch screen, RGB (800×480) | |||
Level output | from -110 dBm to +13 dBm | |||
Modulation Types | AM, FM, PM | |||
Pulse modulation | ≥70 dBc | |||
Interfaces | USB Host, USB Device (USB TMC), LAN (VXI-11, Socket, Telnet) | |||
Dimensions | 338 × 113× 369 mm | |||
Weight | 4,84 kg |
Video
User Manual
Download SIGLENT SSG3021X user manual.
Datasheet
Download SIGLENT SSG3021X datasheet.
Package Contents
- Arbitrary Waveform / Function Generator SIGLENT SSG3021X — 1 pc.
- Cable USB— 1 pc.
- Power Cord — 1 pc.
- Quick start Guide — 1 pc.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
