Optical Power Meter JOINWIT JW3109
id: 901202
Optical Power Meter JOINWIT JW3109
Overview
Description
Delivery
Payment
Warranty
USD 160.00
Add to cart
Overview
1.2 kg
Availability in stock:
HK
Warranty: 6 months The tool provides up to four output wavelengths: 650 nm red source, 1310/1550 nm wavelengths for single-mode fiber, or 850/1300 nm wavelengths for multimode fiber. Read more
Buy wholesale and save
Inform of price reduction
Suggest your price
Your gift (list of the available gifts depends on the amount of your order)
Description
JOINWIT JW3109 is an optical power meter that provides up to four output wavelengths measuring: 650 nm red source, 1310/1550 nm wavelengths for single-mode fiber, or 850/1300 nm wavelengths for multimode fiber.
Features
- Wide range of power measurement: from 650 nm to 1550 nm.
- High stability of the output power.
- Stable output wavelength.
- Backlight LCD.
- Automatic power of after 10 of no-operation.
Application
- Multi-mode and single-mode optical cable testing.
- Fiber optic network maintenance.
Technical Specifications
| Wavelengths | 650 nm | 1310/1550 nm | 850/1300 nm | 850/1300/1310/1550 nm |
| Emitter Type | FP-LD/LED | |||
| Typical Output Power | 0 | -7 dBm (FP-LD) / -20 dBm (LED) | ||
| Spectral Width | < 10 nm | |||
| Output Stability | ±0.05 dB/15 min; ±0.1 dB/8 hours | |||
| Modulation Frequencies | CW, 2 Hz | CW, 270 Hz, 1 KHz, 2 KHz | ||
| Fiber Type | MM, SM | |||
| Optical Connector | FC / universal adaptor | FC/PC | ||
| General Specifications | ||||
|---|---|---|---|---|
| Display | LCD | |||
| Backlight | yes | |||
| Auto Power Off | in 10 minutes | |||
| Working Temperature | -10°C ~ +60°C | |||
| Storage Temperature | -25°C ~ +70°C | |||
| Humidity | 20 - 95% | |||
| Battery Type | AA batteries 1.5 V × 3 pcs. | |||
| Battery life | 45 hours | |||
| Dimensions | 175 mm × 82 mm × 33 mm | |||
| Weight | 300 g | |||
Package Contents
- Optical Power Meter JOINWIT JW3109 — 1 pc.
- Carrying Case — 1 pc.
- Batteries — 3 pcs.
- User Manual — 1 pc.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
