Pocket Digital Multimeter UNI-T UT125C
id: 883712
0.25 kg Warranty: 24 months
The multimeter with 4000 display counts and overload protection. It is an ideal tool for measuring AC/DC voltage and current, resistance, capacitance, frequency, diode and continuity. Read more
Buy wholesale and save
Inform of price reduction
UNI-T UT125C is a palm-sized, stable and reliable multimeter with 4000 display counts and overload protection. It is an ideal tool for measuring AC/DC voltage and current, resistance, capacitance, frequency, diode and continuity.
Features
- Overload protection with the overrange indication.
- Auto power off. The device automatically powers off if no operation for 30 minutes. Press any button to wake up the multimeter.
- Operating temperature: 0°C ~ 40°C.
- Storage temperature: -10°C ~ 50°C.
- Low power indicator.
- Other functions: data hold, NCV, backlight.
Technical Specifications
Function | Range | Accuracy |
---|---|---|
DC Voltage | 400 mV/4 V/40 V/400 V/600 V | ±(0.5%+5) |
AC Voltage | 4 V/40 V/400 V/600 V | ±(1,2%+5) |
DC Current | 400μA/4 mA/40 mA/400 mA | ±(1.8%+5) |
AC Current | 400μA/4 mA/40 mA/400 mA | ±(2,0%+8) |
Resistance | 400 Ω/4 kΩ/40 kΩ/400 kΩ/4 MΩ/40 MΩ | ±(1,0%+5) |
Capacitance | 50 nF/500 nF/5 μF/50 μF/100 μF | ±(4%+10) |
Frequency | 9.999 kHz ~ 60 kHz | ±(0,1%+5) |
Duty Cycle | 20%~80% | |
General Characteristics | ||
Display | LCD 38 × 23 mm, 4000 display counts | |
Dimensions | 112 × 58 × 35 mm | |
Weight | 180 g |
User Manual
Download UNI-T UT125C User Manual.
Video
You'll find even more video reviews in the Video tab. Go and check it out!
Package Contents
- Pocket Digital Multimeter UNI-T UT125C — 1 pc.
Note! Batteries are not included in the package.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
