Super Phosphor Oscilloscope SIGLENT SDS2104X
id: 862783
Super Phosphor Oscilloscope SIGLENT SDS2104X
Overview
Description
Specifications
Video
Delivery
Payment
Warranty
Discontinued
Overview
Video
Video
Video
Video
9 kg 110, 220 V Warranty: 36 months
Desktop 4-channel phosphor digital oscilloscope with 100 MHz bandwidth, 2 GSa/s real-time sample rate, 140 MB memory, 8.0" display and up to 60,000 waveforms/sec capture rate. Read more
Discontinued
You may also like
2 channel Super Phosphor Oscilloscop with a 100 MHz bandwidth, a sample rate of 2 GSa/s, a maximum memory depth of 200 MB and a 10.1" display.
Availability in stock:
HK
ID: 893077 9.8 kg
4 channel Super Phosphor Oscilloscop with a 200 MHz bandwidth, a sample rate of 2 GSa/s, a maximum memory depth of 200 MB and a 10.1" display.
Availability in stock:
HK
ID: 893075 9 kg
Description
SIGLENT SDS2104X is a 4-channel Super Phosphor Oscilloscope with a bandwidth of 100 MHz, a sample rate of 2 GSa/s, and a 140 Mpts memory depth.
Features
- New generation of SPO (Super Phosphor Oscilloscope) technology
- Supports statistics calculations, Gating measurement, Math measurement, Ref measurement
- Waveform math function (FFT, addition, subtraction, multiplication, division, integration, differentiation, square root)
- High Speed hardware based Pass/Fail function
- Large 8 inch TFT-LCD display with 800*480 resolution
- Different interfaces: USB Host, USB Device, LAN, Pass / Fail, Trigger Out, GPIB
User Manual
Download SIGLENT SDS2104X User Manual.
Technical Specifications
| SDS2072X | SDS2074X | SDS2102X | SDS2104X | SDS2202X | SDS2204X | SDS2302X | SDS2304X | |
| Channels | 2 | 4 | 2 | 4 | 2 | 4 | 2 | 4 |
| Bandwidth | 70 MHz | 70 MHz | 100 MHz | 100 MHz | 200 MHz | 200 MHz | 300 MHz | 300 MHz |
| Sample Rate (max.) | 2 GSa/s | |||||||
| Memory Depth | 140 Mpts | |||||||
| Math | +, -, *, /, FFT, d/dt ,∫dt,√ | |||||||
| FFT windows | Rectangle, Hanning, Hamming, Blackman | |||||||
| Time base | 1 ns/div to 50 s/div | |||||||
| Display | 20.32 cm (8") WVGA-Color-LCD, 800 × 480 Pixel | |||||||
| Interface | USB Host, USB Device, LAN, Pass/Fail, Trigger Out, GBIP | |||||||
| Size (W × H × D) | 352 × 224 × 112 mm | |||||||
| Weight | 3.4 kg | |||||||
Video
You'll find even more video reviews in the Video tab. Go and check it out!
Additional Information
Download SIGLENT SDS2104X Data Sheet.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
